2024-2026 Year Version.

When purchasing 2024-2026 version products, please refer to the data below. If the product you have been traded in is the 2021-2023 version, but you want the latest updated version of 2024-2026, please consult sales.

TFMOV 05M_SETsafe & SETfuse.pdf

Datasheet (PDF Document) Include: Specifications, Agency Approvals, Packaging, Structure Diagrams, Glossary, Part Numbering System, Installation, Usage, Replace, Storage and other information.

Samples requests, please click the link.

https://www.setsafe.com/Support/Sample-Request.html

or

Please contact: sales@SETfuse.com

Xiamen SET Electronics Co., Ltd.

Thermally protected varistors - Mechanical release type (TFMOV) are thermally protected varistors that have all the characteristics of a thermistor (MOV) with a thermal protection function. TFMOVs have all the characteristics of a thermally protected varistor (MOV), but with the added benefit of thermal protection.MOVs are subject to two types of deterioration: natural deterioration due to long term operation, and deterioration due to abnormal surges. When a surge occurs, the leakage current of the degraded MOV increases continuously, causing the surface temperature of the MOV to rise continuously and the possibility of fire. At this time, the heat of the MOV in the TFMOV is transferred to the cryogenic alloy solder joint, which senses the abnormal temperature and acts (fuses), driving the spring slider to cut off the circuit, disconnecting the MOV from the main circuit to protect the entire circuit, and the MOV itself will not continue to heat up and catch fire.

● High Reliability

● Small Size

● High flow rate

● Sealing Material, Flame-retardant to V0 (UL 94)

● Designed and manufactured in accordance with UL 1449

● RoHS & REACH Compliant

Through Hole

Solder Pin

You can download the 3D diagram of product structure to help you improve design efficiency to create more great products.

TFMOV05M series_3D_TFMOV_SETsafe & SETfuse.zip

● Communication equipment

● String inverters

● AC and DC power supplies

● Uninterruptible Power Supplies (UPS)

● Surge Protectors (SPD)

● Electricity meters

● Power Distribution Units (PDUs)

● Lightning outlets

ABSOLUTELY ASSURED USE WITH GLOBALIZATION CERTICATION

The following certificates (PDF Documents) are only used for browsing on the web to prove the product has been certified. If you need a full version certificate, Please contact: sales@SETfuse.com

TUV (Germany):

Standards: EN IEC 61643-11, EN IEC 61643-31

File No.: 50603962 / 50603960

TUV_TFMOV_TFMOV05M_SETsafe & SETfuse.pdf

CE (European Union):

Standards: EN IEC 61643-11, EN IEC 61643-31

File No.: 50603238 / 50603249

CE_TFMOV_TFMOV05M_SETsafe & SETfuse.pdf

For product quality, our goal is to be industry-leading. We ensure that the quality of the product meets the expected goals from the following process.

Quality Policy.

Qualified Supplier of Raw Materials.

Incoming Quality Control (IQC):

Acceptance Quality Limit (AQL), Dimension, Function, Visual Inspection, RoHS & REACH Test. etc..

Process:

Online Inspection and Function Test 100%, etc..

In Process Quality Cortrol (IPQC): AQL, Dimension, Function, Visual Inspection, etc..

Final Quality Control (FQC):

AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test, etc..

Reliability Test:

AQL Sampling Test.

Outgoing Quality Control (OQC):

Packaging, Labeling, Quantity Inspection, etc..

Agency Information:

Safety Certificate Agency Annual, Quarterly Audits. Include UL, cUL, VDE, TUV, KC, PSE, CCC. etc..

Quality Management System:

TUV Approved and Issued Certificate.

SETsafe | SETfuse

SET

Thermally Protected Varistors - Mechanically Off Type Thermally Protected Varistors (TFMOV) are thermally protected varistors. TFMOVs have all the characteristics of a thermally protected varistor (MOV), but are also thermally protected. there are two types of deterioration of MOVs: natural deterioration due to long term operation, and deterioration due to an abnormal surge. When a surge occurs, the leakage current of the degraded MOV increases continuously, causing the surface temperature of the MOV to rise continuously and the possibility of fire. At this time, the heat of the MOV in TFMOV is conducted to the cryogenic alloy solder joint, which senses the abnormal temperature and acts (fuses), driving the spring slider to cut off the circuit, disconnecting the MOV from the main circuit and thus protecting the entire circuit, as well as the MOV itself will not continue to heat up, and the phenomenon of catching fire.

Learn more

TFMOV05M series
